Schneider Electric LX1D6E7

(0) 0 Reviews 0 Orders 0 Wish listed

1,481EGP

Quantity :

Total price :

(Tax : )

Overview
Reviews

✅ Schneider Electric LX1D6E7 – Replacement Coil for TeSys D Contactors, 48V AC 50/60Hz Part No.: LX1D6E7 The Schneider Electric LX1D6E7 is a 48V AC replacement coil engineered for TeSys D contactors rated at 80 A and 95 A, including LC1D80 and LC1D95 models. Operating at 50/60 Hz, this coil is ideal for control circuits requiring medium-level AC voltage in industrial and infrastructure applications. Part of the LX1D6 coil series, the LX1D6E7 is built to deliver long mechanical life and reliable performance under continuous-duty conditions. It supports ambient operation up to 60°C and aligns with Schneider Electric’s environmental policies, holding Green Premium, RoHS, and REACh certifications. 🔧 Technical Specifications Attribute Details Product Type Contactor Coil Range TeSys D Device Short Name LX1D6 Part Number LX1D6E7 Control Circuit Voltage [Uc] 48V AC 50/60Hz Frequency 50/60 Hz Compatibility LC1D80…LC1D95 TeSys D Contactors Coil Technology Without built-in suppressor module Application Range 80 A and 95 A Contactors Ambient Temperature (Op.) Up to +60°C Compliance Green Premium, RoHS, REACh 📦 Packaging Details (Standard packaging data assumed unless specified otherwise) Unit Weight: ~0.09 kg Package Type: Single (PCE) Typical Package Dimensions (cm): 6.3 × 4.5 × 4.0 🌍 Environmental Compliance: ✔ RoHS Compliant ✔ REACh Compliant ✔ Green Premium Certified 🔩 Applications: Suitable for 48V AC control voltage systems in industrial motor starters, process automation panels, and high-load electrical infrastructure utilizing TeSys D contactors LC1D80 and LC1D95.
